Model |
|
|
Brand |
MSI |
|
Model |
K9N4 Ultra-F |
|
Supported CPU |
|
|
CPU Socket Type |
AM2 |
|
CPU Type |
Athlon 64 X2 / Athlon 64 / Sempron |
|
FSB |
1000MHz Hyper Transport (2000 MT/s) |
|
Chipsets |
|
|
North Bridge |
NVIDIA nForce 500 Ultra |
|
Memory |
|
|
Number of Memory Slots |
2×240pin |
|
Memory Standard |
DDR2 800 |
|
Maximum Memory Supported |
4GB |
|
Channel Supported |
Dual Channel |
|
Expansion Slots |
|
|
PCI Express x16 |
1 |
|
PCI Express x1 |
1 |
|
PCI Slots |
3 |
|
Storage Devices |
|
|
PATA |
1 x ATA100 2 Dev. Max |
|
SATA 3Gb/s |
4 |
|
SATA RAID |
NV RAID 0/1/0+1 JBOD |
|
Onboard Video |
|
|
Onboard Video Chipset |
None |
|
Onboard Audio |
|
|
Audio Chipset |
Realtek ALC655 |
|
Audio Channels |
6 Channels |
|
Onboard LAN |
|
|
LAN Chipset |
Vitesse VSC8601 |
|
Max LAN Speed |
10/100/1000Mbps |
|
Rear Panel Ports |
|
|
PS/2 |
2'));
2 |
|
COM |
1 |
|
LPT |
1 |
|
USB |
4 x USB 2.0 |
|
Audio Ports |
3 Ports |
|
Onboard USB |
|
|
Onboard USB |
4 x USB 2.0 |
|
Physical Spec |
|
|
Form Factor |
ATX |
|
Dimensions |
12.1" x 7.3" |
|
Power Pin |
24 Pin |
|
Packaging |
|
|
Package Contents |
K9N4 Ultra-F |
