Model
|
Brand
XFX
Model
RX480M8BFA6
Interface
|
PCI
Express 3.0
Chipset
|
Chipset Manufacturer
AMD
GPU Series
AMD
Radeon RX 400 Series
Radeon
RX 480
1288
MHz
Stream Processors
2304
Stream Processors
Memory
|
8000
MHz
Memory Size
8GB
256-Bit
Memory Type
GDDR5
3D
API
|
DirectX
12
OpenGL
4.5
Ports
|
1 x
HDMI
3 x
DisplayPort 1.4
Details
|
Max Resolution
4096
x 2160
Eyefinity Support
Yes
CrossFireX Support
Yes
Virtual Reality Ready
Yes
Cooler
With
Fan
System Requirements
Minimum
Power Supply Requirement: 500W
XFX Recommended Power Supply: XFX 550W PSU
Power Connector
6-Pin
Dual-Link DVI Supported
Yes
Features
|
Features
Microsoft
Windows 10 Support
Microsoft DirectX 12 Support
FinFET 14nm Technology
VR Ready Premium
GCN 4th Generation Architecture
AMD Virtual Super Resolution (VSR)
AMD LiquidVR Technology
AMD FreeSync Technology
AMD Frame Rate Target Control (FRTC)
AMD CrossFire technology
AMD Eyefinity multi-display technology
AMD App Acceleration
AMD TrueAudio Technology
AMD XConnect Ready
AMD Radeon Crimson Software
AMD WattMan
AMD APP Acceleration
HDMI 2.0b
Displayport 1.4
Dolby TrueHD and DTS-HD Master Audio Support
PCI Express 3.0
Up to 6 displays supported, (may require the use of MST Hubs).
Advanced GDDR5 Memory Technology
Vulkan and Mantle Ready. Next Generation APIs
OpenGL 4.5 Support
OpenCL Support
Form
Factor & Dimensions
|
Max GPU Length
254
mm
Card Dimensions (L x H)
10.00"
x 5.00"
Slot Width
Dual Slot
